| 50' 2022 Outback Yachts

Versatility. Efficiency. Performance. Outback Yachts, adhering to the concept of form follows function, has completely re-imagined recreational yachting. The Outback team, seasoned industry veterans, worked with legendary Michael Peters Yacht Design to create an amazingly versatile, extremely efficient, and exceptionally seaworthy yacht. Perfect for day outings, weekend adventures, or open water cruising, her expansive outdoor deck space and practical interior accommodations provides the best in safe and comfortable cruising. Their flagship model, the Outback 50, actually 56’ in length, offers endless possibilities. She draws only 3 feet and has a keel to protect her running gear. With a pair of 480 hp Volvos she delivers speeds to 24 knots. A custom-built version can be delivered in less than a year.

This unique Michael Peters design has the engines and generator placed under the aft deck, rather than under the salon sole. Her conventional straight shaft drive eliminates the complexity of the IPS or V drive alternatives and has a much shorter length shaft than other conventional drive vessels. The fuel and water are positioned over the center of buoyancy, so the trim is never affected by your fluid levels, and all that weight is concentrated where it benefits performance the most. This arrangement creates a smooth, quiet, and comfortable ride. The Outback 50 is also extremely economical with a range of approximately 1200 miles at trawler speeds.

Whether you’re out on the water for the day, a weekend adventure, or a longer offshore cruise, the revolutionary Outback 50 offers endless possibilities.

•tHull topsides and superstructure in general are foam cored FRP composite, with outer layers utilizing vinyl ester resins and E-glass reinforcements throughout the structure.

•tHull is solid FRP laminate below the waterline and form cored FRP above.

•tAll molded FRP parts are finished with high gloss Cook 941 gelcoat.

•tHigh density foam or solid laminates are used in areas of concentrated loads from hardware mounting.

•tMolded propeller tunnels are recessed into hull reducing draft and shaft angle.

•tMain deck is fully cored with flat & cambered sections with transverse & longitudinal support of girders & “hat section” stiffeners.

•tTwin Volvo D6, 480 hp diesels

•tSidePower 24V bow and stern thrusters with proportional speed control

•tIntegrated fresh water heat exchanger cooling system

•t4 blade bronze propellers

•tAquamet #19 propeller shafts

•tTides Marine dripless shaft seals

•tTides Marine dripless rudder seals

•tGroco raw water intake strainers & thru hulls

•tEngine room blower & vent ducts.

•tEngine room floor with FRP non-skid sole

•tGloss white engine room

•tFully insulated sound damping material

•tAnti-vibration mounts on engine stringers

•tTeleflex BA-200 hydraulic steering system (2) station

•tZip Wake trim tabs with gyro to maintain proper trim and reduce roll

• (2) Garmin GPSMAP 8616 chart plotter/sonar combo 17” at flybridge helm and pilothouse

• Garmin Reactor 40 Autopilot w/smart pump v2

• Garmin GMR Fantom 18-inch 40 W solid state Radar

• (2) Garmin VHF 110 radios

•tInstallation is neat and accessible and clearly labeled

•t(1) 550-gallon aluminum fuel tank forward of E/R bulkhead

•t(2) 2” fill lines. One port and one starboard

•tSite gage on fuel tank

•t(2) Racor fuel filters

•t(4) Seaflo 24V bilge pumps with 3-way switches and Ultra float switches

•tBeckson manual bilge pump

•t(2) SS 75-gallon water tanks located at sole

•tCrossover with shutoff valves for filling tanks 150 gallons total

•tJabsco Par Max 4” 24V fresh water pump

•t(2) Jabsco accumulator tanks

•tSeaward F1100 galvanized steel 120V water heater

•tTrionic 14.5 gal 24V sump tank for head sinks & showers

•t80-gallon black water tank

•tSealand T series 24V discharge pump for holding tank

•tSealand Tank Watch 4 depth indicator

•tJabsco seawater deck wash pump

•t(3) Freshwater hose coils at bow, stern and flybridge

•tWhale Twist Deck shower at transom

•tNorthern Lights 12kw generator with sound shield

•tRemote start/stop panel for generator at lower helm

•tGas/water separator muffler for quiet generator operation

•tAC/DC main control panel located near lower helm

•t(4) Mastervolt AGM batteries for house system

•t(2) Mastervolt AGM for engine start

•tMastervolt converter 24/12-24

•t(2) Marinco shore power outlets 50 amp/110v/220v

•tProMariner galvanic isolator and bonding system

•tMastervolt “Battery Mate” isolator

•tMastervolt Chargemaster Plus 24V/60 for house service

•tMastervolt Chargemaster 12V/35 for engine batteries

•tKraus & Naimer transfer switch for forward or aft shore power

•t110 V outlets throughout flybridge, infinity deck and engine room GFCI protected, and waterproof at exterior outlets.

•t24 Volt house system

•tLED lighting throughout with dimmers

•tEffective lighting in all machinery and storage spaces

•tMain deck safety lighting

•t(24) Exterior overhead Infinity deck lighting

•t(5) Hella LED navigation lights – US compliant

•tDometic Marine Air air conditioning and heating system. (2) remote mount compressors with 3 air handlers.

•tMuir Windlass VRC1250 24v with 2 station controls and SS chain stopper

•t50’ ACCO BBB galvanized chain with 300’ 5/8” nylon anchor line

•tBruce style 66 lb. anchor

•tMolded FRP pulpit with SS anchor channel and roller.

•t(4) 12” SS mooring cleats

•t(2) 15” SS mooring cleats at transom

•t(1) 8” SS mooring cleat on platform for snubber line

•t(2) SS Hawse holes located midships

•t(2) SS chocks in way of forward mooring cleats

•tAluminum mast (white powder coat) on flybridge. Hinged to lower bridge clearance to 15'

•t(3) Exalto wiper/washer system with speed control

•tL – shaped lounge, upholstered

•tMolded FRP helm console

•tTodd Marine helm chair with slider assembly

•tSecond Flybridge helm chair option

•t(2) 3” SS stanchions for boat deck support

•tStructural lamination for future davit

•tSS 1 ¼” safety rails port and starboard

•tSS 1 ¼” safety rail surrounding ladder to Infinity deck

•tTinted Plexiglass venturi screen

•tFRP dining table with (2) SS posts

•tHinging Navigation mast. Powder coated aluminum

•t(1) Large engine room access hatch with dual ram electric hydraulic lift

•t(1) Quick access engine room hatch with ladder

•t(1) Large generator room access hatch with dual ram electric hydraulic lift

•t(1) Lazarette access hatch

•tHatches drain to waterline

•tFlexiteek decking for entire deck and swim platform (owner selection)

•tSS retractable ladder to flybridge with teak stair treads

•tPort and starboard FRP bench seats with lift top storage

•tSS (3) piece transom railing system with multiple configurations

•tSS retractable swim ladder with cover on platform

•t(2) Pop up SS cleats on platform

•tSS 1 ¼” safety handrail from Infinity deck to bow

•tLED overhead lighting

•tLED deck safety lighting

LOWER HELM:

•tSliding access door to starboard side deck

•tDual Volvo engine monitoring systems

•tTwin Lever Shift & Throttle Control (EVC-E)

•tTriple windshield wipers w/ multiple speed settings

•tWindshield washers plumbed from the freshwater system

•tRitchie SS 2000 compass

•tSwitch controls for horn, running lights, anchor light, engine room blowers, & bilge pumps

•tCustom SS spoke steering wheel

•tUpholstered bench seat with SS adjustable bolster

•tSS footers

FLYBRIDGE HELM:

•tVolvo engine monitoring systems

•tTwin Lever Shift & Throttle Control

•tRitchie SS 2000 compass

•tSwitch controls for horn, running lights, anchor light, engine room blowers, & bilge pumps

•tCustom SS spoke steering wheel

•tPort and starboard lift top gear storage

•tTodd Marine white helm chair with slider assembly

•t“L” settee with storage

•t5” foam cushions, with storage under

•tHi-low dining/cocktail table with removable leaf

•tEntertainment center with Samsung LED TV with lift

•tSound deadening, soft headliner panels

•tStorage cabinet

•tHinged stainless steel door to cockpit

•tBreaker panel

•tDeep chart table forward of L-settee seat port

•tBeautiful galley with amazing views.

•tStainless steel under mount sink with cover

•t(2) U-Line refrigerators/freezers

•tKenyon 3 burner cooktop

•tMicrowave oven with stainless steel face

•tDrawers and storage lockers below the counter.

•tOverhead cabinets port and starboard

•tIsland queen berth with 9″ foam mattress with laminated teak trim

•tCabinet with 6 drawers on aft bulkhead

•tWhite planked cabin sides with open shelving

•t(2) Manship SS opening portlights

•tManship SS overhead hatch

•t(2) Stainless steel port lights in hull

•t(2) BCM Catalina LED polished reading lights

•tCherry hull ceilings

•tDrawers under berth and in bulkhead aft of berth

•tLarge Hanging locker

•tShelf locker

•tCarpeted sole

•tSound deadening soft headliner panels

• Private access from master stateroom

• All molded FRP head

• Porcelain raised style sink

• Elongated Quartz countertop

• Satin finish teak laminate cabinet below sink

• Opening stainless-steel portlight with screen

• Upper mirror with ample open storage

• Large stall shower with SS framed shower enclosure and quartz seat

• Dual banks of 4 storage drawers

• Rule DC ventilation blower

• Polished chrome towel ring

• Moen faucets for sink/shower

• Tecma head

• Custom marble pebble style sole in head and shower

•tTwin side by side berths with nightstand and engineered countertop

•t6″ foam mattresses and laminated teak trim berth

•tLED Catalina reading lights

•tModern vinyl ceilings with LED lighting

•tDrawer/storage under berth

•tStorage lockers, drawers and shelves

•tCombo white plank paneling and teak veneer side

•tCarpeted sole with access to head ensuite or from companionway

•t(2) Stainless-steel Port lights in hull and opening stainless-steel port light with screen

•tCabinet with 6-drawers on forward bulkhead
