Listed at $7,300,000

Interested in this yacht? Contact Us

I understand that by signing up I agree with 26 North’s Privacy Policy.


Available for SaleHANNA94' 2019 Riva

The stunning and sleek Riva 90 Argo, HANNA, catches the eye for more reasons than one. Designed in partnership by Officina Italiana Design (the studio founded by Mauro Micheli and Sergio Beretta) and Ferretti Group’s Product Strategy Committee (headed by engineer Piero Ferrari) and Engineering Department, this flybridge is an imposing sight. She is a premium quality, pedigree yacht that offers excellent performance and large volume.

The interior spaces include a relaxed salon with magnificent hull-side windows with stainless steel interior framing supports the superstructure and runs around the outside of the full-height glass windows. The spacious lounge is furnished with two lounge chairs, an L-shaped sofa and a TV mounted in a panel with a stainless-steel perimeter and mirrored surfaces. Beyond it is the dining area, with a large table and seats for eight people. A special touch is added by incorporating a panoramic balcony on each side near the windows.

Forward of the dining area is the generous full-beam master suite, with a king-size bed and comfortable lounge area. The ensuite features a double vanity and a spacious shower. The large windows throughout the suite offer natural light and a beautiful view.

A full-beam VIP suite and two center island queen staterooms are located on the lower deck, each with en-suite bathrooms. The crew quarters can accommodate up to four crew in two cabins.

HANNA’s wheelhouse features a state-of-the-art front bridge console, which is finished in leather and fitted with large navigation screens. This area also features a two-person leather seating area aft of the captain’s seat.

The hull is finished in Grey Metallic with a Black Boot stripe and a Teal Mist boot accent stripe.

26 North Yachts is pleased to assist you in the purchase of this vessel. This boat is centrally listed by Fraser Yachts. It is offered as a convenience by this broker/dealer to its clients and is not intended to convey direct representation of a particular vessel

Specifications

LOA: 94' (29 m)
Beam: 20' (7 m)
Hull Material: Fiberglass
Fuel Capacity: 2,298 gal (8,699 L)
Fresh Water Capacity: 349 gal (1,322 L)
Flag: Jamaica
Location: Florida, Fort Lauderdale, United States
Build Year: 2019
Builder: Riva
Model: 90 ARGO
Type: Motor Yachts
Cruising Speed: 25 Knots
Max Speed: 30 Knots
Engine Information:
  • Engine Make: MTU
  • Engine Model: 16V2000 M84
  • Engine Year:
  • Engine Type: Inboard
  • Power (HP): 2218.00
  • Power (KW): 1653.96
  • Fuel Type: Diesel
  • Hours: 715.00
  • Engine Location: Port

Details

SPECIFICATIONS

MAIN CHARACTERISTICS

Name: HANNA

Type: Motor Yacht

Builder: RIVA

Year: 2019

Yacht Model: 90 Argo

LOA (M/FT): 28.49 M 93’ 06”

LWL (M/FT): 23.10 M 75’ 09”

Beam (M/FT): 6.5 M 21’ 04”

Draft (M/FT): 2.13 M 7’

Gross Tonnage: 123

Displacement: 220,462 lbs Full Load

Hull Material: GRP

Hull Configuration: Planning

Superstructure Material: GRP

Flag: Jamaican

Port of Registry: Montego Bay

Naval Architect: Ferretti Engineering Department

Exterior Designer: Officina Italiana Design

Interior Designer: Officina Italiana Design

Main Engine: 2 x MTU 16V2000 M84 – 2,218hp

Speeds: 28 Max

23 Cruising

Range: 300 nm @ 22knots

Guest Accommodation: 8 guests in 4 staterooms

Crew Accommodation: 4 crew in 2 cabins

NOTEWORTHY FEATURES AT A GLANCE

• 23 knots cruising speed with a maximum speed up to 27 knots

• Zero speed stabilization with fins and SeaKeeper gyro stabilization

• Three spacious outdoor entertainment areas

• Vast on-deck owner’s suite with lounge and en-suite

• Accommodates 8 guests in 4 expansive staterooms

ACCOMMODATIONS

OVERWIEW:

Launched in 2019, Hanna is a premium quality, pedigree yacht that offers excellent performance and large volume. Her contemporary modern interior was inspired by the idea of combining sporty lines, forward thinking design with carefully chosen modern furniture and finished in beautiful satin Italian walnut.

ACCOMMODATIONS:

This exceptionally maintained 90 Argo is in impeccable condition and offers spacious accommodation for eight guests. The arrangement comprises an on-deck master suite, a VIP double and two guest cabins that can be configured as double or twin berths. Each stateroom features an en-suite.

LOWER DECK:

Forward of the dining area is a winding stairway with stainless handrails and glass siding that leads to the lower guest foyer and staterooms. Aft of the stairs is the full-beam VIP with a centerline, sole leather upholstered queen bed with drawers for storage. Forward of the stairs are two double cabins that can be converted to twin beds. Each guest room is faceted with modern furniture, a 32’ TV and entertainment system, ample closet space with additional storage under the beds, and an en-suite. All guest bathrooms feature Calcatta Austale marble floors and sinks.

MAIN DECK:

On the main deck, a large frame supports the superstructure and runs around the outside of the full-height glass windows. The spacious lounge covering almost 40m² is open to the sea and reaches heights of over 2.1 m. It is furnished with two lounge chairs, an L-shaped sofa, and a retractable TV. Beyond it is the formal dining area, with a large table and seating for eight guests. A special touch is added by incorporating a panoramic balcony on each side near the windows.

OWNER’S STATEROOM:

Forward of the guest stairway, owners are welcomed into their on-deck suite with large windows that allow natural light to beam through on both sides. Centerline is a queen-sized bed, framed in sole leather upholstery and stainless-steel polished details with a bed lifting system to allow for additional storage underneath. Lacquered nightstands with doors in sole leather and a glass top sit on each side of the bed. Matching storage furniture and large vanity is located on the starboard side along with a wardrobe with a mirror and ample space. The en-suite is set with Calcatta Australe Marble and his and her sinks, with lacquered walls.

FLYBRIDGE DECK:

Access to the flybridge is up the stairs from either the aft deck or pilot house. A second fibreglass varnished control station with up-down system for forward display, upholstered steering wheel, instrumentation, compass, and alarm lights sits forward near the pilot house entrance. An additional dining table and L shape sofa with upholstered cushions, two helm chairs, and floating furniture aft provides substantial space for entertaining. Side cabinets with electric opening system top, equipped with sink, 24V refrigerator, storage and electric grill are located opposite the dining table.

CREW ACCOMODATION:

The crew area is accessed from the main deck galley. The crew mess features an L-shaped sofa, teak table and crew kitchen. There are two crew cabins with pullman bed and private head for a total of 4 crew berths.

GARAGE

The aft garage features an electrohydraulic platform. She houses a Williams SportJet 395 as well as a SeaDoo RXT X300 JetSki

CONSTRUCTION

Hull Material: GRP

Hull Type: Warped hull with spray rails and aft deadrise 12°

Superstructure Material: GRP

Decks Material: Fibreglass floor laid in teak

Motor Hull Type: Raised Pilot House

Motor Hull Sub Type: Flybridge

Number of Decks: 3

CAPACITIES

Gross Tonnage: 123 GT

Displacement Tons: 85 tonnes

Fuel Capacity (GRP Tank): 8,700 Litres 2,298 Gallons

Fresh Water Capacity: 1,320 Litres 349 Gallons

Water Makers (per day): 6,354 Litres 1,400 Gallons

Grey Water: 535 Litres 141 Gallons

Black Water: 535 Litres 141 Gallons

MAIN MACHINERY

Main Engines: 2 x MTU 16V2000 M84 2218hp (Upgrade over std)

Engine Hours: Port: 715 hrs (Recorded 11/2/2022)

Starboard:715 Hrs (Recorded 11/2/2022)

Propulsion Type: V-Drive transmission

Engines Exhaust System: Underwater silenced exhausts

Engine Ventilation: Electric ventilation fans (2)

GENERATORS & ELECTRICITY

Generators: Main electric generator (27kW) Auxiliary generator (19kw)

Generator Hours: Port: 1,240 hrs (Recorded on 11/2/2022)

Starboard: 1,290 hrs (Recorded on 11/2/2022)

Shore Power: 400V with cable

Shore Power Transformer: Three/monophase isolation transformer 400V-230V

Batteries: Group of auxiliary service batteries 24V

Group of batteries for engine starting 24V

Lighting throughout 24V

Main generator battery 12V

Battery Chargers: Automatic battery charger (2) for auxiliary service batteries 24V

Automatic battery charger for engine batteries 24V

Generator Start: Auxiliary generator starting battery 12V

AUXILIARY MACHINERY

Steering System: E-Steer Electro-hydraulic steering system

Bow Thruster: Hydraulic bow thruster (50hp), Electric bow thruster control panel with

joystick

Stern Thruster: Yes, 32HP

Stabilizers: 2 x Seakeeper Gyro Stabilizers (Series 16 and Series 9) ($165,000 option)

Stabilizer fins underway and zero speed (2)

Humphree Trim stabilizers (interceptors)

Bilge System: Electric pump for bilge drainage (engine room)

Electric pumps (4) (1 engine room, 3 accommodation area)

Emergency bilge suction pipe (engine room) through engine cooling pump

Multipurpose electric pump (bilge, grey water, black water)

Fuel Filters: Double Racor fuel filters (2) for engines

Fresh Water Makers: Seafari Watermaker 1400 gpd ($17,000 option)

Hot & Cold Circulation Pump: 230V

Hot Water Boilers: Water heaters 50lt 230V (2)

Sea Water Pumps: Sea water firefighting system with chain wash down

WC's (toilets/bidets): Electric WC System with fresh water

Sanitary Vacuum System: Interchangeable automatic electric pump for black and grey water tanks pumping down

Air Conditioning: Mediterranean air conditioning system

Galley Ventilation & Extraction: Electric

NAVIGATION & COMMUNICATION SYSTEMS

Navigation Bridge: Black box integrated system (radar, plotter, GPS, echo-sounder, monitoring)

Monitors: SIMRAD 16" LCD/LED monitor (4)

Auto Pilot: Automatic pilot with rudder angle indicator interfaced with plotter/GPS

Echo Sounder: Yes

GPS: Colour LCD Plotter/GPS

Search Lights: Adjustable searchlight controlled from the helm station and upper bridge

VHF Radiotelephones: Class D VHF radio telephone with DSC and separate antenna

DECK MACHINERY & EQUIPMENT

Anchors: 2 x Polished stainless-steel anchors 90Kg

Anchor Chains: 2 x Galvanised steel chain, 120m 13mm diameter

Anchor Windlass System: Electric anchor winches 3000W (2) with controls at the helm station, at bow and on the flybridge

Cranes: Number, Brand, Model, Max Load

Warping Capstans: Electric winches for stern warping 1700W 24V (2)

Garage: Electro-hydraulic stern garage fibreglass hatch

Swim Platform: Fiberglass swimming platform with integrated starboard side stair, teak floor and equipped with up & down system

Stern Boarding Gangway: Concealed stainless steel electro-hydraulic gangway with stanchions and teak flooring

Swimming Ladder: Concealed stainless steel electro-hydraulic swimming ladder built into the swimming platform

Spotlights: LED spotlights

Garage: Electric winch for tender lifting/launching

Electro-hydraulic hatch

GRP flooring with non-slip surface

Paint Exterior: Custom color for hull, deck and aft ($295,000 option)

SAFETY, SECURITY, & FIRE FIGHTING EQUIPMENT

CCTV: Colour camera (2) CCTV

Fixed Firefighting System: Emergency pull handles for engines and generators for diesel break (automatic with fire protection system)

FM200 fire extinguishing system in the engine room with automatic / manual control

Firefighting Equipment: Fire-fighting hose (2) at bow and stern

Extinguisher for garage with fire port from the cockpit

Smoke Detection: Yes

Life Rafts: Life rafts for 10 people (2)

Lifejackets: Inflatable life jackets (20)

Life Rings: Life ring with luminous float and line

ENTERTAINMENT, AUDIO/VISUAL AND IT SYSTEMS

Video Equipment: KVH SAT KVH Tracvision HD7

TVRO: US SAT Receivers in guest cabins

Audio Equipment: A/V Package premium sound external

Light Management: Dimmers throughout

Main Salon: 40” LED TV 49” LED TV Mini Hi-fi CD/DVD & Bluetooth

Master Stateroom: 49” LED TV Mini Hi-fi CD/DVD & Bluetooth

VIP Stateroom: 49” LED TV Mini Hi-fi CD/DVD & Bluetooth

Guest Staterooms: LED TV 32" Mini Hi-fi CD/DVD & Bluetooth

Flybridge Deck: Terrestrial TV antenna. VHF antenna (2). Radar antenna. Running and anchor lights. Watertight loudspeakers connected to the stereo in the lounge (2).

Pilot House: Acoustic alarm for water in bilge. Automatic pilot with rudder angle indicator interfaced with plotter/GPS.

Crew Mess: TV 24” A/NTSC USA with CD/DVD/MP3

GALLEY EQUIPMENT

Cooking Equipment: Oven, cooktop, microwave and cooker hood.

Oven/Cookt Top: Miele H2890 B ROK/ Miele KM 7594 FL

Refrigeration/Freezer: GE GZS221 Side-by-side

Dishwasher: Miele G 6880 SCV1

Other: Corian sink with mixer tap, Corian Worktop, Wine Storage/Chiller (salon)

OTHER EQUIPMENT

Sun Awnings: Sundeck area manual Bimini with Carbon Poles, Glass HT roof in lieu of electric Bimini top, Manual awning at Bow.

TENDERS & TOYS

Tenders: Williams SportJet 395

Jet Skis: SeaDoo RXT X300 JetSki

Toys: 2 x Seabobs

Disclaimer

The company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change or withdrawal without notice.
